1. The area of ​​the roof of the building is 2,000 square meters or more
2. Operators that consume more than 20,000 electrical units during the peak period per month (see the electricity bill)
3. Need to produce electricity for own use or to save energy.

1. Electricity bill for the building or area that needs to be installed for the past 1 year (if there is no data for at least the previous 6 months)
2. The roof plan or the area on the roof to be installed
3. Electricity usage data every 15 minutes or data from AMR, if any

1. Project participants Submit basic information for SolarPV to design the installation.
2. SolarPV proposes proposals for participants to consider
3. Agreed to enter into a conditional contract with SolarPV

• If passing preliminary consideration from financial institutions To proceed
• Failure to pass preliminary consideration from financial institutions the contract is cancelled unless the project participants wish to use their own funds. That contract can continue

4. Start the process of requesting permission from a government organization together with installation.
5. Deliver installation work With warranty and maintenance contract
6. Go to check the economical results obtained after installation

1. The quoted price includes transportation, installation, and system testing and delivery surveys to the employer.
2. The price quoted includes a 2 year system warranty with the details as follows

• The company will guarantee the system according to the type and equipment installed. As the work is delivered if there is a defect or damage, the company will fix the system to be able to produce electricity as before. Without any cost
• The company will go to check the system 6 months at a time. (For a period of 2 years, 4 times) after that If the O&M contract is signed, the company will go to check the system 2 times a year, every 6 months.

• Survey, design and inspect the original structure
• Coordination for BOI request, with 50% investment deduction for 3 years
• Monitoring system (excluding monitor, excluding internet system)

• Renovate existing structures (if any)
• High voltage system
• LAN and internet
• Import tax (if any)

Guarantee and Performance Guarantee

For Jinko / Tier 1 panel, warranty and other brands

Guarantee of electricity production capability

• The company will guarantee the solar panel for a period of 25 years by the solar panel manufacturer.
• 10 years for panel assembly warranty
• Guaranteed solar panels will receive no less than 80% of total panel energy in the first 25 years.

For Schutten panel,

Guarantee of electricity production capability

• The company will guarantee the solar panel for a period of 25 years by the solar panel manufacturer.

CHUBB Insurance

• 12 years for panel assembly warranty
• Guaranteed solar panels will receive no less than 90% of total panel energy in the first 12 years.
• Guaranteeing solar panels will receive no less than 80% of total panel energy in the next 13 years

Installation warranty

The company will guarantee leakage. And damage caused by the installation of the company Itself for a period of 2 years

• The system has modified or changed the equipment. In addition to the model Or the company has installed And deliver the work from the beginning
• The system has changed. Change device Or receiving damage from other people
• The system is damaged by natural disasters, accidents, and unexpected events such as lightning, fire, flooding, and others. (Customers can insure with external insurance companies)

Scope of service

1. Clean the solar panel once a year
2. Maintenance and maintenance of the inverter in a preventive manner
3. Inspect the solar panel receiving structure by observing (Physical Visual Inspection)
4. Maintenance of Server and Software systems, including communication systems (Server and Software maintenance)

Steps for system administration and maintenance

1. 1. Clean the solar panel once a year
   • To enable efficient and continuous power generation of the system, the presence of dust that adheres to the solar panel’s surface causes the efficiency to decrease Therefore, it is necessary to clean the solar panels once a year for the first 2 years that the company has guaranteed. After that, it can sign an O&M contract for the company to continuously look after.
   • Cleaning by using a sponge moistened with clean water to wipe the solar panel and dry with a clean cloth again to free from dust or stains. Avoid using various drugs. To erode the use of bubbles and fabrics, be careful not to have dust, rocks and sand which can scratch the glass. The circuit board is not able to support the weight of the person standing on the panel. To clean
   • Inspection by observing the condition and Common defects include

• See the color change of solar cells
• The fog or mist touching the coated glass surface
• See if the laminate film is peeling off or not
• Does water leak into the interior?
• Examine structural fasteners, bolts, screws, and connections that support solar panels.
• Check that the electrical cables are in good condition and ready for use.

2. 2. Maintenance and maintenance of the inverter in a preventive manner

2.1 Read various information including errors that occurred as data for maintenance

2.2 clean the air filter Inlet area

2.3. Checking the terminals and connectors May be too loose or too tight

2.4. Check the insulation of the wires if damaged, hurry to change immediately.

2.5 Inspect the warning label if torn or damaged to hurry to change

2.6 Function tests such as checking the current in the breaker

• Check fuse of connecting devices and various lubricants, if any

2.8 Inspect the equipment; check the electric current or the excess voltage

3. 3. Inspect the solar panel receiving structure by observing (Physical Visual Inspection)

• Solar panel inspection (PV Visual Inspection)

• Detection of solar cells is there damage or not using a heat detector.
• The junction box and the electrical wire are in good condition without damage or burns
• The frame structure of the solar panel is in strong condition, firmly fixed
• Inspect the damages to the electrical wires, ground systems, connection points Must be in good condition
  • Support Structure
• Inspect the galvanizing coatings In the condition of cracks, peeling or rusting
• To be amended By scrubbing brush out and repeating with cold galvanize
• Checking the level and orientation of the structure, is it tilted or damaged?
• View area conditions Structure located In a healthy state or not
• Check the bolts and screws to tighten.

2. Maintenance of Server and Software systems, including communication systems

Check the Server and Software that are still working or not. If found, edit
